Phoenix Clipfix 35-5 End Clamp

DescriptionCommercial dataItem number3022276Packing unit50 pcMinimum order quantity1 pcSales key32Product keyBE7111Catalog pagePage 538 (C-3-2019)GTIN4017918194154Weight per piece (including packing)4.858 gWeight per piece (excluding packing)4.65 gCustoms tariff number39269097Country of originDE Technical data Product propertiesProduct typeEnd bracket Width5.15 mmHeight48.6 mmDepth35.3 mmDepth on NS 35/7.536.5 mmDepth on NS 35/1544 mmLength48.6 mm Material specificationsColorGrayMaterialPAFlammability rating according to UL 94V0Static insulating material application in cold-60 °CRelative insulation material temperature index (Elec., UL 746 B)65 °CFire protection for rail vehicles (DIN EN 45545-2) R22HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2) R23HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2) R24HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2) R26HL 1 – HL 3 Environmental and real-life conditions Ambient conditionsAmbient temperature (operation)-60 °C … 65 °C (max. short-term operating temperature RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, not exceeding 24 h, -60 °C to 70 °C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (storage/transport)30% … 70% MountingMounting typeNS 35/7,5 NS 35/15ETIMETIM 9.0EC001041UNSPSCUNSPSC 21.039121400 Environmental product compliance EU RoHSFulfills EU RoHS substance requirementsYes, No exemptions China RoHSEnvironment friendly use period (EFUP)EFUP-E No hazardous substances above the limits   EU REACH SVHCREACH candidate substance (CAS No.)No substance above 0.1 wt%
