Phoenix End 8 Stop E-UK

DescriptionCommercial dataItem number1201442Packing unit50 pcMinimum order quantity1 pcSales key32Product keyBE7111Catalog pagePage 538 (C-3-2019)GTIN4017918017323Weight per piece (including packing)9,428 gWeight per piece (excluding packing)9,1 gCustoms tariff number39269097Country of originCN Technical data Product propertiesProduct typeEnd bracke Connection dataTightening torque… 0.8 Nm DimensionsWidth9.5 mmHeight50.5 mmDepth35.3 mmDepth on NS 35/7,536.8 mmLength50.5 mm Material specificationsColorGrayMaterialPAFlammability rating according to UL 94V0Temperature index of insulation material125 °CRelative insulation material temperature index125 °C (Elec., UL 746 B) Environmental and real-life conditions Ambient conditionsAmbient temperature (operation)-60 °C … 105 °C (max. short-term operating temperature RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, not exceeding 24 h, -60 °C to 70 °C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (storage/transport)30 % … 70 %MountingMounting typeNS 35/7,5 NS 35/15 Classifications ECLASSECLASS-11.027141135ECLASS-12.027141135ECLASS-13.027250302ETIMETIM 9.0EC001041UNSPSCUNSPSC 21.039121400Environmental product compliance EU RoHSFulfills EU RoHS substance requirementsYes, No exemptions China RoHSEnvironment friendly use period (EFUP)EFUP-E No hazardous substances above the limits EU REACH SVHCREACH candidate substance (CAS No.)No substance above 0.1 wt%
