Phoenix End Cover 2.5mm

DescriptionCommercial DataItem number3001022Packing unit50 pcMinimum order quantity1 pcSales key10Product keyBE1Z1XCatalog pagePage 458 (C-1-2019)GTIN4017918089771Weight per piece (including packing)1,736 gWeight per piece (excluding packing)1,603 gCustoms tariff number85389099Country of originDE Technical data Product propertiesProduct typeEnd cover Environmental and real-life conditions Ambient conditionsAmbient temperature (operation)-60 °C … 105 °C (max. short-term operating temperature RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, not exceeding 24 h, -60 °C to 70 °C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (storage/transport)30 % … 70 % Material specificationsColorGrayMaterialPA 6.6Flammability rating according to UL 94V0Static insulating material application in cold-60 °CTemperature index of insulation material130 °C (DIN EN 60216-1 / VDE 0304-21)Relative insulation material temperature index (Elec.)130 °C (UL 746 B)Fire protection for rail vehicles (DIN EN 45545-2)R22 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2)R23 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2)R24 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2)R26 HL 1 – HL 3Calorimetric heat release NFPA 130 (ASTM E 1354)28 MJ/kgSurface flammability NFPA 130 (ASTM E 162)PassedSpecific optical density of smoke NFPA 130 (ASTM E 662)PassedSmoke gas toxicity NFPA 130 (SMP 800C)Passed DimensionsWidth1.5 mmHeight42.5 mmDepth30.7 mm Classifications ECLASSECLASS-11.027141133ECLASS-12.027141133ECLASS-13.027250301 ETIMETIM 9.0EC000886UNSPSCUNSPSC 21.039121400 Environmental product compliance EU RoHSFulfills EU RoHS substance requirementsYes, No exemptions China RoHSEnvironment friendly use period (EFUP)EFUP-E No hazardous substances above the limits EU REACH SVHCREACH candidate substance (CAS No.)No substance above 0.1 wt%
