Phoenix End Cover D-Ptv 2.5/4 1088746

DescriptionItem number1088746Packing unit1 pcMinimum order quantity1 pcSales keyBE2Product keyBE2Z1XGTIN4055626890272Weight per piece (including packing)2.39 gWeight per piece (excluding packing)2.272 gCustoms tariff number85389099Country of originIN D-PTV 2,5/4 – End cover1088746Technical DataProduct PropertiesProduct typeEnd cover Environmental and real-life conditionsAmbient conditionsAmbient temperature (operation)-60 °C … 105 °C (max. short-term operating temperature RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, not exceeding 24 h, -60 °C to 70 °C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (storage/transport)30 % … 70 % Material SpecificationsColorGrayMaterialPAFlammability rating according to UL 94V0Static insulating material application in cold-60 °CRelative insulation material temperature index (Elec., UL 746 B)130 °CFire protection for rail vehicles (DIN EN 45545-2)R22 HL 1 – HL 3, R23 HL 1 – HL 3, R24 HL 1 – HL 3, R26 HL 1 – HL 3Surface flammability NFPA 130 (ASTM E 162)PassedSpecific optical density of smoke NFPA 130 (ASTM E 662)PassedSmoke gas toxicity NFPA 130 (SMP 800C)Passed DimensionsWidth2.2 mmHeight50.8 mmDepth35.3 mm D-PTV 2,5/4 – End cover1088746ClassificationsECLASSECLASS-11.027141133ECLASS-12.027141133ECLASS-13.027250301 ETIMETIM 9.0EC000886 UNSPSCUNSPSC 21.039121400 D-PTV 2,5/4 – End cover1088746 Environmental product complianceEU RoHSFulfills EU RoHS substance requirementsYes, No exemptions China RoHSEnvironment friendly use period (EFUP)EFUP-E No hazardous substances above the limits EU REACH SVHCREACH candidate substance (CAS No.)No substance above 0.1 wt%
