Phoenix End Cover D-Ptv 6

DescriptionCommercial dataItem number1180894Packing unit50 pcMinimum order quantity1 pcSales keyBE2Product keyBE2Z1XGTIN4063151215576Weight per piece (including packing)3.55 gWeight per piece (excluding packing)3.55 gCustoms tariff number85389099Country of originCN Technical data Product propertiesProduct typeEnd cover Environmental and real-life conditions Ambient conditionsAmbient temperature (operation)-60 °C … 105 °C (max. short-term operating temperature RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, not exceeding 24 h, -60 °C to 70 °C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (storage/transport)30 % … 70 % Material specificationsColorGrayFlammability rating according to UL 94V0Static insulating material application in cold-60 °CRelative insulation material temperature index (Elec., UL 746 B)130 °CFire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2) R23HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2) R24HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2) R26HL 1 – HL 3Surface flammability NFPA 130 (ASTM E 162)passedSpecific optical density of smoke NFPA 130 (ASTM E 662)passedSmoke gas toxicity NFPA 130 (SMP 800C)passed DimensionsWidth2.2 mmEnd cover width2.2 mmHeight61 mmDepth36 mm Classifications ECLASSECLASS-11.027141133ECLASS-12.027141133ECLASS-13.027250301 ETIMETIM 9.0EC000886 UNSPSCUNSPSC 21.039121400 Environmental product compliance EU RoHSFulfills EU RoHS substance requirementsYes, No exemptionsChina RoHSEnvironment friendly use period (EFUP)EFUP-E No hazardous substances above the limitsEU REACH SVHCREACH candidate substance (CAS No.)No substance above 0.1 wt%
