Phoenix Feed-Through Terminal Block Ptv 4

DescriptionCommercial DataValueItem Number1088728Packing Unit1 pcMinimum Order Quantity1 pcSales KeyBE2Product KeyBE2311GTIN4055626890555Weight per Piece (including packing)7.461 gWeight per Piece (excluding packing)6.42 gCustoms Tariff Number85369010Country of OriginCNTechnical data Product PropertiesValueProduct TypeFeed-through terminal blockProduct FamilyPTVIndustryRailway industry, Machine building, Plant engineeringArea of ApplicationProcess industryNumber of Connections2Number of Rows1Potentials1  Insulation CharacteristicsValueOvervoltage CategoryIIIDegree of Pollution3  Electrical PropertiesValueRated Surge Voltage8 kVMaximum Power Dissipation1.02 W    Connection DataValueNumber of Connections per Level2Nominal Cross Section4 mm²Stripping Length9 mm … 11 mmInternal Cylindrical GaugeA4, B3Connection in accordance with StandardIEC 60947-7-1Conductor Cross Section (Rigid)0.2 mm² … 6 mm² (AWG 24 … 10 converted according to IEC)Conductor Cross Section (Flexible)0.2 mm² … 6 mm² (AWG 24 … 10 converted according to IEC)Conductor Cross Section (Ferrule without Plastic Sleeve)0.2 mm² … 4 mm²Flexible Conductor Cross Section (Ferrule with Plastic Sleeve)0.2 mm² … 4 mm²Conductor Cross Section (2 Conductors with TWIN Ferrule)0.5 mm² … 2.5 mm²Nominal Current32 AMaximum Load Current36 A (with 6 mm² conductor cross section, rigid)Nominal Voltage1000 VConnection Cross Sections Directly PluggableConductor Cross Section Rigid: 0.75 mm² … 6 mm²  Conductor Cross SectionRangeFlexible (Ferrule without Plastic Sleeve)1.5 mm² … 4 mm²Flexible (Ferrule with Plastic Sleeve)1.5 mm² … 4 mm²  Ex DataValueIdentificationII 2 G Ex eb IIC GbOperating Temperature Range-60 °C … 110 °C1088746D-PTV 2,5/43030721ATP-ST 41204517SZF 1-0,6X3,5Ex-Certified Accessories3022276 CLIPFIX 35-5List of BridgesPlug-in Bridge / FBS 2-6Plug-in Bridge / FBS 3-6Plug-in Bridge / FBS 4-6Plug-in Bridge / FBS 5-6Plug-in Bridge / FBS 10-6Plug-in Bridge / FBS 20-6Plug-in Bridge / FBS 50-6Bridge Data27 A / 4 mm²Ex Temperature Increase40 K (27.3 A / 4 mm²)Rated Voltage550 VFor Bridging with Bridge550 V– At Bridging Between Non-adjacent Terminal Blocks352 V– At Cut-to-Length Bridging275 V– At Cut-to-Length Bridging with Cover275 V– At Cut-to-Length Bridging with Partition Plate550 VRated Insulation Voltage500 VOutput(Permanent)  Ex Level GeneralValueRated Current27 A (4 mm²)Maximum Load Current31 A (6 mm²)Contact Resistance0.5 mΩ   Ex Connection Data GeneralValueNominal Cross Section4 mm²Rated Cross Section AWG12Connection Capacity Rigid0.2 mm² … 6 mm²Connection Capacity AWG24 … 10Connection Capacity Flexible0.2 mm² … 6 mm²Connection Capacity AWG24 … 10   DimensionsValueWidth6.2 mmEnd Cover Width2.2 mm  Height50.8 mmDepth35.3 mmDepth on NS 35/7,536.8 mmDepth on NS 35/1544.3 mm Material SpecificationsValueColorGrayFlammability RatingV0Insulating Material GroupIInsulating MaterialPAStatic Insulating Material Application in Cold-60 °CTemperature Index of Insulation Material125 °CRelative Insulation Material Temperature Index (Elec., UL 746 B)130 °CFire Protection for Rail Vehicles (DIN EN 45545-2) HL 1 – HL 3Fire Protection for Rail Vehicles (DIN EN 45545-2) HL 1 – HL 3Fire Protection for Rail Vehicles (DIN EN 45545-2) HL 1 – HL 3Fire Protection for Rail Vehicles (DIN EN 45545-2) HL 1 – HL 3Calorimetric Heat Release27.5 MJ/kgSurface FlammabilityPassedSpecific Optical Density of SmokePassedSmoke Gas ToxicityPassed Electrical TestsValueSurge Voltage TestTest passedShort-Time Withstand Current (4 mm²)0.48 kAResultTest passedPower-Frequency Withstand VoltageTest Voltage Setpoint2.2 kVResultTest passed Mechanical DataOpen side panelYes   Mechanical StrengthResultTest passed    Attachment on the CarrierResultTest passed Rotation speed10 rpmRevolutions135Conductor cross section/weight0.2 mm² / 0.2 kg4 mm² / 0.9 kg6 mm² / 1.4 kg0.2 mm² / 0.2 kgResultTest passed   AgingTemperature cycles192ResultTest passed   Needle-flame testTime of exposure30 sResultTest passed          Oscillation/broadband noiseSpecificationDIN EN 50155 (VDE 0115-200):2018-05SpectrumService life test category 2, bogie-mountedFrequencyf1 = 5 Hz to f2 = 250 HzASD level6.12 (m/s²)²/HzAcceleration3.12gTest duration per axis5 hTest directionsX-, Y- and Z-axisResultTest passed   ShocksPulse shapeHalf-sineAcceleration30gShock duration18 msNumber of shocks per direction3Test directionsX-, Y- and Z-axis (pos. and neg.)ResultTest passed Ambient ConditionsValueAmbient temperature (operation)-60 °C … 110 °C (Operating temperature range incl. self-heating; for max. short-term operating temperature, see RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, no longer than 24 h, -60°C to 70°C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (operation)20 % … 90 %Permissible humidity (storage/transport)30 % … 70 %  Standards and RegulationsValueConnection in acc. with standardIEC 60947-7-1  MountingValueMounting typeNS 35/7,5NS 35/15   ECLASSValueECLASS-11.027141120ECLASS-13.027250101  ETIMValueETIM 9.0EC000897  UNSPSCValueUNSPSC 21.039121400 EU RoHSValueFulfills EU RoHS substance requirementsYes, No exemptions China RoHSValueEnvironment friendly use period (EFUP)EFUP-ENo hazardous substances above the limitsYes EU REACH SVHCValueREACH candidate substance (CAS No.)No substance above 0.1 wt%
