Phoenix Feed-Through Terminal Block Ptv 6

DescriptionCommercial DataValueItem number1116734Packing unit50 pcMinimum order quantity1 pcSales keyBE2Product keyBE2311GTIN4063151043063Weight per piece (including packing) 14.3 gWeight per piece (excluding packing)13.228 gCustoms tariff number85369010Country of originCN  Product PropertiesValueProduct typeFeed-through terminal blockProduct familyPTVArea of applicationRailway industry Machine building Plant engineering Process industryNumber of positions1Number of connections2Number of rows1Insulation characteristics Overvoltage categoryIIIDegree of pollution3  ctrical PropertiesValueRated surge voltage8 kVMaximum power dissipation for nominal condition1.31 W4o  Connection DataValueNumber of connections per level2Nominal cross section6 mm²Stripping length10 mm … 12 mmInternal cylindrical gageA5Connection in accordance with standardIEC 60947-7-1Conductor cross section rigid0.5 mm² … 10 mm²Cross section AWG20 … 8 (converted according to IEC)Conductor cross section flexible0.5 mm² … 10 mm²Conductor cross section, flexible [AWG]20 … 8 (converted according to IEC)Conductor cross section flexible (ferrule without plastic sleeve)0.5 mm² … 6 mm²Flexible conductor cross section (ferrule with plastic sleeve)0.5 mm² … 6 mm²2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve0.5 mm² … 4 mm²Nominal current41 AMaximum load current52 A (with 10 mm² conductor cross section, rigid)Nominal voltage1000 VNominal cross section6 mm²  Connection Cross Sections Directly PluggableValueConductor cross section rigid1.5 mm² … 10 mm²Conductor cross section, rigid [AWG]16 … 8 (converted according to IEC)Conductor cross section flexible (ferrule without plastic sleeve)4 mm² … 6 mm²Flexible conductor cross section (ferrule with plastic sleeve)2.5 mm² … 6 mm² Ex DataValueIdentificationII 2 G Ex eb IIC GbOperating temperature range-60 °C … 110 °CEx-certified accessories41180894 D-PTV 6 3022276 CLIPFIX 35-5 1212602 SZS 0,6X3,5 VDEList of  bridgePlug-in bridge / FBS 2-8 / 3030284 Plug-in bridge / FBS 3-8 / 3030297 Plug-in bridge / FBS 4-8 / 3030307 Plug-in bridge / FBS 5-8 / 3030310 Plug-in bridge / FBS 6-8 / 3032470 Plug-in bridge / FBS 10-8 / 3030323Bridge data36 A / 6 mm²Ex temperature increase40 K (35 A/6 mm²)Rated voltage550 VFor bridging with bridge550 V– At bridging between non-adjacent terminal blocks352 V– At bridging between non-adjacent terminal blocks via PE terminal block352 V– At cut-to-length bridging220 V– At cut-to-length bridging with cover275 VRated insulation voltage500 VOutput(Permanent) Ex Level GeneralValueRated current35 A (6 mm²)Maximum load current45 A (10 mm²)Contact resistance0.5 mΩ  Ex Connection Data GeneralValueNominal cross section6 mm²Rated cross section AWG10Connection capacity rigid0.5 mm² … 10 mm²Connection capacity AWG20 … 8Connection capacity flexible0.5 mm² … 10 mm²Connection capacity AWG20 … 8 DimensionsValueWidth8.2 mmEnd cover width2.2 mmHeight61 mmDepth42.2 mmDepth on NS 35/7,543.7 mm Material SpecificationsValueColorgrayFlammability rating according to UL 94V0Insulating material groupIInsulating materialPA 6.6Static insulating material application in cold-60 °CTemperature index of insulation material (DIN EN 60216-1 (VDE 0304-21))125 °CRelative insulation material temperature index (Elec., UL 746 B)125 °CFire protection for rail vehicles (DIN EN 45545-2)R22 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2)R23 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2)R24 HL 1 – HL 3Fire protection for rail vehicles (DIN EN 45545-2)R26 HL 1 – HL 3Calorimetric heat release NFPA 130 (ASTM E 1354)27.5 MJ/kgSurface flammability NFPA 130 (ASTM E 162)passedSpecific optical density of smoke NFPA 130 (ASTM E 662)passedSmoke gas toxicity NFPA 130 (SMP 800C)passed Surge Voltage TestValueTest voltage setpoint8 kVResultTest passed emperature-rise TestValueRequirement temperature-rise testIncrease in temperature ≤ 45 KResultTest passedShort-time withstand current 6 mm²0.72 kAResultTest passed Mechanical propertiesMechanical data Open side panelYesMechanical strength ResultTest passed    Attachment on the carrier DIN rail/fixing supportNS 35  ResultText passed Mechanical Test: Rotation and Conductor WeightValueRotation speed10 rpmRevolutions135Conductor cross section/weight0.5 mm²/0.3 kg 6 mm²/1.4 kg 10 mm²/2 kgResultTest passed  Aging TestValueTemperature cycles192ResultTest passed Oscillation/broadband noiseValueSpecificationDIN EN 50155 (VDE 0115-200):2018-05SpectrumService life test category 2, bogie-mountedFrequency rangef1 = 5 Hz to f2 = 250 HzASD level6.12 (m/s²)²/HzAcceleration3.12gTest duration per axis5 hTest directionsX-, Y- and Z-axisResultTest passed          Shock TestValueSpecificationDIN EN 50155 (VDE 0115-200):2018-05Pulse shapeHalf-sineAcceleration30gShock duration18 msNumber of shocks per direction3Test directionsX-, Y- and Z-axis (pos. and neg.)ResultTest passed   Ambient ConditionsValueAmbient temperature (operation)-60 °C … 110 °C (Operating temperature range incl. self-heating; for max. short-term operating temperature, see RTI Elec.)Ambient temperature (storage/transport)-25 °C … 60 °C (for a short time, no longer than 24 h, -60°C to 70°C)Ambient temperature (assembly)-5 °C … 70 °CAmbient temperature (actuation)-5 °C … 70 °CPermissible humidity (operation)20 % … 90 %   Permissible Humidity (Storage/Transport)ValuePermissible humidity (storage/transport)30 % … 70 %     Standards and regulations Connection in acc. with standardIEC 60947-7-1 Mounting  Mounting typeNS 35/15 Classifications ECLASS-11.027141120ECLASS-13.027250101 ETIM ETIM 9.0EC000897 UNSPSC  UNSPSC 21.039121400 Environmental product complianceEU RoHS Fulfills EU RoHS substance requirementsYes, No exemptionsChina RoHS Environment friendly use period (EFUP)EFUP-E No hazardous substances above the limits EU REACH SVHC REACH candidate substance (CAS No.)No substance above 0.1 wt%
